BX616 Portable Multi-gas Detector

Small size and light-weight

Simple operation with only 1 button

Battery low voltage alert

Measuring gas: O2, CO, H2S and Combustible

Dimension & weight: 120×68×30mm, about 220g

Ingress protection: IP66

Download

Description

BX616 is a united gas detector measuring four (4) major gases, which result the most of the industrial accidents, to protect the disasters caused by the O2 deficiency, toxic gas poisoning and combustible gas explosion. It measures continuously four gases O2, CO, H2S and combustible gas (CH4), and displays their concentrations. Once the risk occurs, it also raises the alarm (visual, audible and vibrative).

Features

Small size and light-weight

Simple operation with only 1 button

Adjustable alarm levels and span calibration value

STEL and TWA alarm for toxic gases

Self protection for combustible gas sensor against high concentration

Battery low voltage alert

Confidence beep

Self-test after power on

Self-diagonstic and self-correction function

Application

Steelworks, petrochemical plant, oil industry, shipbuilding yard, sewage treatment plant, mine, power supply works, confined spaces etc.

Specifications

Measuring gas O2 CO H2S Combustible
Measuring range 0-30%VOL 0-1000ppm 0-100ppm 0-100%LEL
Sensor type Electrochemical Electrochemical Electrochemical Catalytic
Measuring type Diffuse naturally
Response time T90<30s
Display LCD screen
Audible ≥85dB at 1m
Alarm method Visual, audible and vibrative signals
Battery DC3.7V 1800mAh Lithium battery
Operating life ≥8h per charge (Charging time: 4-6h)
Event log 2000 events
Working temperature Toxic gases: -20℃~50℃   Combustible: -40℃~70℃
Working humidity    <95%RH (no condensation)
Housing Rubber enclosure
Standard accessories Operation manual, calibration cap, charger, screwdriver
Dimension & weight 120×68×30mm, about 220g
Ex grade  II 2G   Ex ia IIC T4 Ga or II 2G   Ex db ia IIC T4 Gb
Ingress protection IP66
